enquiry@asip.com.myFingertec AC100C
Door Access System --- FINGERTEC ---
| Previous ‹‹ | » Next |
|
Eliminate Buddy Punching Card system doesn’t solve ‘buddy- punching’ problem where one employee can clock for another employee. Eliminate ‘buddy- punching’ by using user’s fingerprint as identity. |
|
Cloud-Ready Technology AC100C comes with the latest PUSH technology, suitable for FCC data storage and convenient for TimeTec TA. The technology eliminates the need for manual data download process.. |
|
Manage Data Easily TCMS V3 is loaded with useful features complete with various reports for your business. Its data integration to 3rd party software is made available through the readily available SDK. |
|
Full Colour Screen AC100C comes with a full color TFT screen. It supports display of corporate advertisements, screen- savers and more. |
|
Workcodes Let your staff experience more independence by reporting their whereabouts via our workcodes feature.
|
|
Data Management Simplified FingerTec AC100C is equipped with TCP/IP connectivity and when that is not available, a USB flash port can be used to transfer transaction logs into your computer. |
|
Precise Recognition A100C uses minutiae point matching fingerprint technology, an advanced algorithm to match the stored fingerprint template with the live one to guarantee authenticity. |
|
Value for Money This model was designed to be economical so that you are able to implement FingerTec solutions at a lower cost. We believe that when it comes to security, there should be no compromise. |
| Layout Plan |
| for illustration only * Optional |
| SPECIFICATIONS | |
| MODEL | AC100C |
| SURFACE FINISHING | Acrylonitrile butadiene styrene (ABS) |
| TYPE OF SCANNER | Non coated optical scanner |
| MICROPROCESSOR | 800 MHz |
| MEMORY | 256 MB flash memory & 128 MB SDRAM |
| ALGORITHM | BioBridge VX 9.0 / VX 10.0 |
| PUSH TECHNOLOGY | Yes |
| PRODUCT DIMENSION (L X W X H), mm | 195 x 48 x 144 |
| STORAGE | |
| • Fingerprint templates | 8000 |
| • Transactions | 200000 |
| ENROLLMENT & VERIFICATION | |
| • Methods | Fingerprint (1:1, 1:N) & password |
| • Recommended fingerprint per user ID | 2 |
| • Fingerprint placement | Any angle |
| • Verification time (sec) | < 1 |
| • FAR (%) | < 0.0001 |
| • FRR (%) | < 1 |
| COMMUNICATIONS | |
| • Method | TCP/IP, USB disk (Optional: RS232 & RS485) |
| • Baud rates | 9600, 19200, 38400, 57600, 115200 |
| OPERATING ENVIRONMENT | |
| • Temperature (°C) | 0 ~ 45 |
| • Humidity (%) | 20 ~ 80 |
| • Power input | DC 5V 2A |
| TIME ATTENDANCE | |
| • Work codes | Yes |
| • Fast transaction checking | Yes |
| MULTIMEDIA | |
| • Voice | Yes |
| • Display | 3.0” 65k color TFT screen |
| • Short messaging | Yes |
| • Photo ID | Yes |
| VOICE / DISPLAY LANGUAGE (TERMINAL) |
English (Standard), Arabic, Indonesian, Chinese (Simplified), Cantonese / Chinese (Traditional), Thai, Vietnamese, Spanish, Portuguese (Portugal), French, Russian, German, Turkish & Persian Other languages are available upon request. |
| SOFTWARE LANGUAGE | Arabic, Bulgarian, Chinese (Simplified), Chinese (Traditional), English, German, Hindi, Indonesian, Kurdish, Malay, Portuguese, Russian, Spanish, Thai, Vietnamese |
Brouchure:https://cdn1.npcdn.net/attachments/15546926850af13fd259011654fa8e50c31a31187f.pdf
