BG-2060 CU.Mixer Amplifier

     PA/Sound System ---    TOA    ---

Previous ‹‹ » Next

BG-2060 CU.Mixer Amplifier

The BG-2060 is a 60 W 5-input mixer amplifier for background music and general announcement. It is suited for use in bars, retail stores, and banquet rooms, and is equipped with the MOH OUT that permits 2-channel broadcast when used in conjunction with the optional booster amplifier BA-235 (35 W) or BA-260 (60 W).

Specifications:



Power Source 120 V AC, 60 Hz
Rated Output 60 W
Power Consumption 163 W (rated output), 80 W (based on cULus standards)
Frequency Response 50 Hz - 20 kHz
Total Harmonic Distortion 0.5 % or less, at 1 kHz, rated output
Input Mic: -60 dB*, 600 Ω, electronically balanced, removable terminal block
Line 1: -10 dB*/ TEL: -20 dB*
Line 1/TEL selectable, 10 kΩ, electronically balanced, removable terminal block
Line 2, 3: -10 dB*, 10 kΩ, unbalanced, removable terminal block and RCA jacks
Module
Output Speaker: 4 Ω, 25 V (10 Ω), 70 V (83 Ω), balanced, removable terminal block
MOH: 0 dB*, 600 Ω, balanced, removable terminal block
Line: 0 dB*, 600 Ω, unbalanced, removable terminal block
Output Regulation 2 dB or less, no load to full load (1 kHz)
Phantom Power On/Off switch for Mic, +24 V DC
S/N Ratio Mic: 60 dB or more, Line 1/TEL, Line 2, 3, Module: 75 dB or more
(Band Pass: 20 Hz - 20 kHz, Tone Controls: Centered)
Muting Manual mute/Automatic mute
Tone Control Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz
Control Mic gain control, Line 1/TEL gain control, Line 2 gain control, Line 3 gain control,
Module gain control, Bass tone control, Treble tone control, MOH out gain control,
Mute control (Manual mute), Remote volume control, Mute sense control,
Line 1/TEL selector switch, Phantom power switch (Mic),
Auto mute switch (Mic, Line 1/TEL, Module),
Mute receive switch (Mic, Line 1/TEL, Line 2, 3, Module),
MOH assign switch (Mic, Line 1/TEL, Line 2, 3, Module), Power ON/OFF switch
Indicator Power LED, Signal level LED, Peak LED
Operating temperature 0 to +40 (32 bF to 104 bF)
Operating Humidity 35 % to 80 %RH (no condensation)
Finish Panel: ABS resin, black
Case: Steel plate, black, paint
Dimensions 264 (W) × 94.3 (H) × 267.3 (D) mm (10.39' × 3.71' × 10.52')
Weight 5.3 kg (11.68 lb)
Accessory Volume control cover: YA-920 ……5, Removable teminal plug (2 pins) ……4,
Removable teminal plug (3 pins) ……2, Removable teminal plug (4 pins) ……1,
Removable teminal plug (5 pins) ……1
Option Rack mounting bracket: MB-1000






Brochure: https://cdn1.npcdn.net/attachments/1459480866ec62fedc8b24e1b0073c8ff1f7b1d003.pdf
